JACKS AND PLUGS
JACK COVERS PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
JACK COVERS
Reliable, spring-loaded covers effectively seal front panel
bushing openings from dust and dirt when mating plugs are
not connected to jack. Series 500 is mounted with conventional
threaded bushing jacks. Special locknut (comes with Series
500 jack covers) seals tightly against rubber washer when
cover is closed. Series 600 is used with certain type tip jacks.
Due to variable jack dimensions, two .031" washers are supplied.
SPECIFICATIONS
MATERIAL
Base and Cover: Steel per QQ-S-698; finish per
MIL-F-14072 (Sig. C), enamel, semi-gloss.
Axle: Copper alloy per QQ-W-321, Type 321,
composition B. Plated per QQ-P-416, Type II, Class 3.
Spring: Stainless steel per QQ-W-432, Type 302.
Hex Nut: Copper alloy per QQ-B-626, composition 22.
Same plating as axle.
Gasket: Synthetic rubber per MIL-R-6855, Type II,
35-40 Durometer.
Washer (600 only): Steel per QQ-S-698; plated per
QQ-P-416, Type II, Class 3.
Additional Specifications for Numbers 512 and 612:
Same as above, except rivet, base, cover and hex nut
and washer (Number 612 only) are nickel-plated
per QG-N-290.
515
520
Part
Part
Part
Part
Color
Olive Drab
Bright Nickel
No.
510
512
No.
? 610
612
Color
Black
Navy Gray
No.
515
520
No.
615
? 620
? Special order only. Contact Switchcraft.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
